Stainless Steel Threaded Pipe Flange

Stainless Steel Threaded Pipe Flange refers to a flange connected by thread and pipe. It is a kind of non-welded flange, which processes the inner hole of the flange into pipe threads. Compared with flat welding flange or butt welding flange, this  threaded pipe flange has the advantages of easy installation and maintenance, and can be used in some pipelines where welding is not allowed. It also has good corrosion resistance and can be used for a long time.

Technical Specs

●Item Threaded Flange

●Pipe Fitting Material Forged 316 Stainless Steel

●Fitting Schedule/Class Class 300

●Pipe Size - Pipe Fitting 2"

●Fitting Connection Type FNPT

●Max. Pressure 720 psi

●Max. Steam Pressure 300 psi

●Outside Dia. 6-1/2"

●Number of Holes 8

●Standards ASTM-SA182, ANSI B16.5, ASME B1.20.1

Advantages

●Raised face: 1/16"

●Forged stainless steel material conforms to ASME A182

●Forged stainless steel flange dimensions conform to ASME B16.5

●Manufacturing facility is ISO 9001:2008
